Step 8—Required Information for Bespoke Rooflight Sizes
To ensure that each bespoke rooflight is
correctly manufactured, the measurements
required are clarified in the descriptions
and accompanying diagrams below and
overleaf.
Glazing only (X-Glaze) and
Adaptor Kerbs
|
To fix X-Glaze (domes and pyramids) and
rooflights with adaptor kerbs to a kerb
that has been pre-built the measurements
required are shown in the diagram and
itemised below.
A & B overall finished kerb sizes
including all added insulation and
weatherproofing finishes.
C & D internal finished sizes including
all well liners.
* Min 150 mm from finished roof surface.
Rooflights that Include a Kerb Supplied by Xtralite
|
Care must be taken to ensure the fixing
point of the rooflight kerb locates onto
solid ground to ensure a secure fixing.
The measurements shown in the
diagram and itemised below are the
required details.
A & B the roof opening size.
